Xylan Coatings

Stovrite are specialists in Xylan Coating

Xylan Coating is a solvent-borne, resin bonded high temperature resistant dry film with additional corrosion inhibitors, formulated for use on threaded components to deliver a wide range of performance characteristics in multiple industrial applications.

• Benefits



  • Controlled low friction
  • Very wide in-service temperature range
  • Very good corrosion resistance
  • Very good chemical resistance
  • Usable as stand-alone or as part of an overall coating system
  • Wide range of colors



• Suggested End Uses




  • Bolts
  • Studs
  • Valve Stems
  • Other Threaded Components





  Technical Properties*





  *TYPICAL FILM PROPERTIES DETERMINED OVER HEAVYWEIGHT ZINC PHOSPHATE PRE-TREATMENT ON MILD STEEL SUBSTRATE ¹CORROSION RESISTANCE DETERMINED OVER XYLAR 2 PRIMER ON MILD STEEL SUBSTRATE ²CHEMICAL RESISTANCE BY SPOT TEST, OVER 24 HOURS AT ROOM TEMPERATURE





  Property	Standard	Results
  Dry-film thickness	ASTM D7091-20	15 – 25 μm
  Dynamic coefficient of friction	ASTM G99-17	Static 0.124 / Dynamic 0.047
  Corrosion resistance¹	ASTM B117-18 / ASTM D610-08	≤5,000 hours / ≤Rust Grade 10
  Pencil hardness	ASTM D3363-20	2H - 4H
  Adhesion	ASTM D3359-17	5B
  Chemical resistance²	ASTM 1308-20	Hydrochloric Acid (pH 2) - slight mark; MEK - slight mark

For more information on our Xylan Coating services please contact our specialist team on 0191 438 6612
